SW1X ‘Xcalibur’ Horn Loudspeakers
The Xcalibur loudspeakers are genuine acoustically loaded, folded 100% horn design following the same design paramaters of our Lady Pearl Horns made from Granite Epoxy Composite.
The main design goals of the Xcalibur Horns are
- Single, Full Range Driver of higest Quality, X-overless Design
- Ultimate Musicality with Absolute Phase Coherance
- Crystal Clear Transparency
- Lifelike Dynamics with Ultra Low Distortion Low Frequency Reproduction
- Ideal Impedance Load, Easy to drive by Low Power, Single Ended, Class A Amplifiers
SW1X Audio Design™ Xcalibur Horn Features:
- Genuine, acoustically loaded folded Horn design
- Cross-over-less Design
- Single 2 in 1 (10″ and 3″ diameter) Fullrange driver with Paper Cone, Cloth Suspension and Solid Wood Phase Plug
- or 3 in one (9″, 6″ and 3″ diameter) Concentric, Oval Fullrange driver with Paper Cone, Cloth Suspension and Solid Wood Phase Plug
- Available in 2 versions: with AlNiCo magnet or Field Coil
- Housed in massive (150kg each) cabinets, every wooden part manufactured from piano instrument grade Birch plywood
- Fine tuned Cabinet is made with 5-axis CNC machinery for maximum consistency
- Horn Cabinet is glued throughout, only few metal screws to fix the drivers are employed
- Internally wired exclusively with our SW1X Magnum, Genesis and Opus Copper or Silver (on request) conductors
- Mid Horn is Gloss finished in real Shellac, a natural lacquer resin
- Bass Horn is finished in satin with natural lacquer, rigorously selected for its sound, beauty and durability
- Non-synthetic lacquer satin finish is standard, other wood finishes are possible on request
Drivers
Specifications
Minimum recommended Power Amplifier Output (W): 1
Average Sensitivity (dB/W/m): 100
Minimum Impedance (Ohm): 8
Frequency Response: flat from 50Hz-20kHz
Dimensions: Height (mm) 1250 x Width (mm) 1000 x Depth (mm) 800
Weight (kg): 150 each cabinet
